Catalogue Number: PPH301CH

  • Not Compatible with Header Systems

  • Self-Centering When within 15 Degree of Closed Position

  • Three Year Warranty
  • Use Monolithic Tempered Glass

  • The CRL Adjustable Prima Series makes mounting top and bottom hinges easier than ever. Adjusting up to 5 degree both in and out to the desired door alignment can be done after the initial installation. The small Allen screws on the front and rear of the base plate are loosened using the provided 3 mm Allen Wrench, allowing positioning of the door to the desired closing position. Tightening the Allen screws ensures that the door closes to the same position every time.

    CRL Polished Chrome Adjustable Prima Series Hinge


    Other Products/Finishes:

    PPH301CH CRL Polished Chrome Adjustable Prima Series Hinge
    PPH301BR CRL Polished Brass Adjustable Prima Series Hinge
    PPH3010RB CRL Oil Rubbed Bronze Adjustable Prima Series Hinge
    PPH301BN CRL Brushed Nickel Adjustable Prima Series Hinge
    PPH301PN CRL Polished Nickel Adjustable Prima Series Hinge
    PPH301SC CRL Satin Chrome Adjustable Prima Series Hinge

    Catalogue Number:PPH301CH
    Also Available in These Catalogues:
    CRL23R Frameless Showerscreen and Mirror Hardware, PAGE 119J
    SD16 Frameless Showerscreen Hardware 2015, PAGE 133S
    CRL93A Showerscreen, PAGE SD049
    Colour:Polished Chrome
    Height:2" (51 mm)
    Width:3-5/8" (92 mm)
    Ship Via:Can Ship UPS
    Shipping Weight:1 lb (454g)
    Minimum Order:1 Each

    NOTE: Not compatible with Header Systems.

    Using two hinges with 5/16" to 3/8" glass (8 to 10 mm) the hinge will hold up to 100 lbs. (45 kg) with a maximum width of 31" (787 mm).

    Glass Thickness: 5/16" (8 mm) to 3/8" (10 mm) Tempered Safety Glass
    Construction: Solid Brass
    Hinge Swings: Full Rotation
    Closing Type: Self-Centering when within 15 degree of closed position.
    Cut-Out Required
    Includes: Gaskets, Screws, 3 mm Allen Wrench, and Glass Fabrication Dimensions
    This hinge series is patented (Patent No. 5,297,313).

    CRL Shower Door Hinges are designed for residential or hotel shower use. If hinges are to be used for other than their intended purpose, approval must be obtained from the CRL Shower Door Technical Sales Department. Use only the template included with this hinge. Cut-out dimensions for CRL hinges may not match those of other brands.
