Catalogue Number: GEN337CH
Finish: POLISHED CHROME


  • Adjustable to Any Angle Up to 90 Degrees without Removing Door

  • Available in Several Beautiful Finishes
  • Three Year Warranty
  • Adjustable Wall Mount Full Back Plate
  • Use Monolithic Tempered Glass

  • The CRL Adjustable Geneva Series has taken our popular Geneva Hinge to a new level. Adjustment to accommodate the desired angle (up to 90 degree) is done after the door is installed. Once the door is hung, simply loosen the Allen set screws and turn the door to the desired closed position. By merely tightening the Allen screws your door will self-center to the desired closing position. The door can swing 90 degree inward and 90 degree outward (adjusting angle from factory set position will reduce 90 degree swing in that direction). For doors pulling outwards only (using a clear door jamb), you can adjust the hinge to close 5 degree inside the shower area, thus having the door close snugly against the jamb.



    CRL Polished Chrome Geneva 337 Series Adjustable Wall Mount Full Back Plate Hinge





    Other Products/Finishes:

    CATALOGUE NUMBER DESCRIPTION COLOUR
    GEN337CH CRL Polished Chrome Geneva 337 Series Adjustable Wall Mount Full Back Plate Hinge
    GEN337BR CRL Polished Brass Geneva 337 Series Adjustable Wall Mount Full Back Plate Hinge
    GEN3370RB CRL Oil Rubbed Bronze Geneva 337 Series Adjustable Wall Mount Full Back Plate Hinge
    GEN337ABR CRL Antique Brass Geneva 337 Series Adjustable Wall Mount Full Back Plate Hinge
    GEN337ABRZ CRL Antique Bronze Geneva 337 Series Adjustable Wall Mount Full Back Plate Hinge
    GEN337BC0 CRL Brushed Copper Geneva 337 Series Adjustable Wall Mount Full Back Plate Hinge
    GEN337BN CRL Brushed Nickel Geneva 337 Series Adjustable Wall Mount Full Back Plate Hinge
    GEN337MBL CRL Matte Black Geneva 337 Series Adjustable Wall Mount Full Back Plate Hinge
    GEN337PN CRL Polished Nickel Geneva 337 Series Adjustable Wall Mount Full Back Plate Hinge
    GEN337SB CRL Satin Brass Geneva 337 Series Adjustable Wall Mount Full Back Plate Hinge

    Catalogue Number:GEN337CH
    Also Available in These Catalogues:
    SD16 Frameless Showerscreen Hardware 2015, PAGE 115S
    CRL23R Frameless Showerscreen and Mirror Hardware, PAGE 142J
    CRL93A Showerscreen, PAGE SD012
    Colour:Polished Chrome
    Height:3-1/2" (89 mm)
    Width:2-3/16" (56 mm)
    Ship Via:Can Ship UPS
    Shipping Weight:2 lb (907g)
    Minimum Order:1 Each

    Using two hinges with 5/16" to 1/2" glass (8 to 12 mm) the hinge will hold up to 80 lbs. (36 kg) with a maximum door width of 28" (711 mm).

    Using three hinges with 5/16" to 1/2" glass (8 to 12 mm) the hinge will hold up to 120 lbs. (54 kg) with a maximum door width of 32" (813 mm).

    SPECIFICATIONS:
    Glass Thickness: 5/16" (8 mm) to 1/2" (12 mm) Tempered Safety Glass
    Special Features: Adjustable to any angle up to 90 degree without having to take door down.
    Construction: Solid Brass
    Hinge Swings: 90 degree in and 90 degree out (at factory set position).
    Closing Type: Self-Centering when within 15 degree of closed position.
    Cut-Out Required Includes: Gaskets, Screws, and Glass Fabrication Dimensions. Cat. No. GEN13 Gasket Pack must be purchased separately for use with 5/16" (8 mm) thick tempered glass.

    NOTE: Door glass width may require alteration from standard clearance deductions when adjusting angles. Call for details.

    Custom finishes are available on request. Contact the CRL Technical Sales Shower Door Department.

    CRL Shower Door Hinges are designed for residential or hotel shower use. If hinges are to be used for other than their intended purpose, approval must be obtained from the CRL Shower Door Technical Sales Department. Use only the template included with this hinge. Cut-out dimensions for CRL hinges may not match those of other brands.
