PERT90CH - CRL Perth Series 'T' Configuration Back-to-Back Glass Hinge Polished Chrome
C.R. Laurence of Australia Pty Ltd.
Connecting the World to Everything Glass
 YOUR ACCOUNT               VIEW CART                SIGN INSIGN OFF


View Larger Image

Catalogue Number: PERT90CH
Finish: POLISHED CHROME


  • Solid Brass Construction

  • Glued in Gaskets

  • Suitable for 10 mm Thick Glass
  • Recommended Glass to Glass Clearance: 8 mm

  • The Perth Series of professional hinges are pre-set to accommodate 10 mm thick glass. The gaskets are glued into the hinge, promoting rapid installation. Composed of solid brass, the spring will self center within 25 degrees of the closed position and will open both inwards and outwards. The hardware is available in three standard finishes - Chrome, Brushed Nickel and Matt Black.



    CRL Perth Series 'T' Configuration Back-to-Back Glass Hinge Polished Chrome





    Other Products/Finishes:

    CATALOGUE NUMBER DESCRIPTION COLOUR
    PERT90BN CRL Perth Series 'T' Configuration Back-to-Back Glass Hinge Brushed Nickel
    PERT90CH CRL Perth Series 'T' Configuration Back-to-Back Glass Hinge Polished Chrome
    PERT90MBL CRL Perth Series 'T' Configuration Back-to-Back Glass Hinge Matt Black

    Catalogue Number:PERT90CH
    Also Available in These Catalogues:
    This item is currently only available in Australia and surrounding areas
    Colour:Polished Chrome
    Wide Plates:55 mm
    High:90 mm
    Suitable for:10 mm Thick Glass
    Ship Via:No UPS - Common Carrier Only

    Using two hinges 36 kg with a maximum door width of 711 mm.
    Using three hinges 54 kg with a maximum door width of 813 mm.

    SPECIFICATIONS:
    Glass Thickness: 10 mm
    Construction: Solid Brass
    Hinge Swings: 90 degree in and 90 degree Out
    Gaskets: Glued in Preset for 10 mm Thick Glass
