Catalogue Number: DW5200A
Finish: SATIN ANODIZED


  • XOX Double Slider Configurations in Four Finishes

  • Each Unit is Customized to Your Needs

  • Finished Available: Satin Anodized, Bronze Anodized, Powder or KYNAR® Painted, and custom Anodized


  • This CRL Manual Deluxe Sliding Service Window is perfect when one window is required for two clerks helping customers at the same time. The unit has three divided panels, two sliders and a center fixed panel that is twice the width of the sliders. This allows for both sliding panels to be operated simultaneously. Each window is custom made to your exact specifications. The heavy-duty design and construction will give years of maintenance-free operation. Models are available with or without screens.



    CRL Satin Anodized DW Series Manual Deluxe Sliding Service Window XOX with Screen





    Other Products/Finishes:

    CATALOGUE NUMBER DESCRIPTION COLOUR
    DW5200A CRL Satin Anodized DW Series Manual Deluxe Sliding Service Window XOX with Screen
    DW5200DU CRL Duranodic Bronze DW Series Manual Deluxe Sliding Service Window XOX with Screen
    DW5200K CRL Custom KYNAR® Paint DW Series Manual Deluxe Sliding Service Window XOX with Screen
    DW5200P CRL Custom Color Powder Painted DW Series Manual Deluxe Sliding Service Window XOX with Screen

    Catalogue Number:DW5200A
    Also Available in These Catalogues:
    CRL53R Glass & Glazing Catalogue, PAGE 609G
    TH18 Transaction and Security Hardware Catalogue, PAGE T413
    Colour:Satin Anodized
    Width :Custom Dimension
    Height:Custom Dimension
    Panels :O = Fixed, X = Sliding
    Ship Via:No UPS - Common Carrier Only

    Features:
  • Removable Header Access Panel to Enable Servicing
  • Adjustable Sliding Panel to Compensate for Uneven Counter Surfaces
  • Upgraded Full Length Heavy-Duty Ball Bearing Carrier
  • Newly Designed Self-Locking Handle

    Available Glazing Options:
  • 1/4" (6 mm) Tempered, Laminated, Tinted, Wire
  • 9/16" (14 mm) Laminated
  • 1/2" (12 mm) Tempered, Laminated, Tinted, Insulating
  • 5/8" Insulating

    Available Options:
  • Keyed Lock
  • Full Bottom Track
  • Burglar Bar
  • Laminated Counter Shelf
  • Stainless Steel Counter Shelf
  • Surrounding Frames to Form Side Lites
  • Transoms to Fill Large Openings
  • Open Counter Area
  • Deal Tray
  • Fly Fan Switch
  • Air Curtain
