Catalogue Number: S0GC91CH
Finish: CHROME


  • For 5/16" to 1/2" (8 to 12 mm) Thick Glass
  • Use Monolithic Tempered Glass
  • Adjustable from 90 to 180 Degrees

  • Solid Brass
  • Assists with Shear Forces
  • Holds Glass Panels in Position While Sealant Cures

  • CRL Sleeve Over Glass Clamps are designed to provide a mechanical fastener to cover the shear forces placed on the glass panels. No special fabrication of the glass is required. Can also be used to secure the glass panels in position while the applied silicone sealant in the joint cures (the silicone sealant glues the glass panels together, prevents water leakage, and provides the pull strength to keep the panels from separating). Clamps are secured in place by nylon tipped Allen set screws.



    CRL Chrome Adjustable "Sleeve Over" Glass Clamp





    Other Products/Finishes:

    CATALOGUE NUMBER DESCRIPTION COLOUR
    S0GC91CH CRL Chrome Adjustable "Sleeve Over" Glass Clamp
    S0GC91ULBR CRL Unlacquered Brass Adjustable "Sleeve Over" Glass Clamp
    S0GC91BR CRL Brass Adjustable "Sleeve Over" Glass Clamp
    S0GC910RB CRL Oil Rubbed Bronze Adjustable "Sleeve Over" Glass Clamp
    S0GC91BBRZ CRL Brushed Bronze Adjustable "Sleeve Over" Glass Clamp
    S0GC91BN CRL Brushed Nickel Adjustable "Sleeve Over" Glass Clamp
    S0GC91MBL CRL Matte Black Adjustable "Sleeve Over" Glass Clamp
    S0GC91PN CRL Polished Nickel Adjustable "Sleeve Over" Glass Clamp
    S0GC91SC CRL Satin Chrome Adjustable "Sleeve Over" Glass Clamp

    Catalogue Number:S0GC91CH
    Also Available in These Catalogues:
    SD16 Frameless Showerscreen Hardware 2015, PAGE 195S
    CRL53R Glass & Glazing Catalogue, PAGE 279G
    CRL23R Frameless Showerscreen and Mirror Hardware, PAGE 295J
    CRL93A Showerscreen, PAGE SD103
    Colour:Chrome
    Ship Via:Can Ship UPS
    Shipping Weight:8 oz (227g)
    Minimum Order:1 Each

    SPECIFICATIONS:
    Material: Solid Brass
    Glass Thickness Range: 5/16" to 1/2" (8 to 12 mm)
    No Glass Fabrication Required (Clamps tighten using nylon tipped Allen screws).
    Includes: Gaskets

    NOTE: These Clamps are not designed to take the place of Headers or a Support Bar. Contact CRL Frameless Shower Technical Sales Department for more details. Can be used on both square cut or mitered panels.

    These Clamps are not designed to take the place of Headers or a Support Bar.
