RC79CH - CRL Polished Chrome Round Fixed Panel U-Clamp
C.R.LaurenceC.R. Laurence of Australia Pty Ltd.
Connecting the World to Everything Glass
 YOUR ACCOUNT               VIEW CART                SIGN INSIGN OFF

View Larger Image

Catalogue Number: RC79CH
Finish: CHROME

  • Clean Sleek Lines
  • Use Monolithic Tempered Glass
  • Round Shape is Especially Suited for Use with Our Hydroslide Sliding Unit and Vertical Post System
  • Quick and Easy Installation
  • Available in Several Finishes
  • Glass Thickness Range: 5/16" to 1/2" (8 to 12 mm)

  • Our solid brass CRL Round Style Fixed Panel Clamps are designed to secure glass panels in contemporary shower enclosures. They assist in maintaining the frameless appearance and provide a clean looking alternative to U-Channel. The round shape of this Clamp looks especially attractive when securing fixed panels of glass used with our Hydroslide Sliding Glass System, Vertical Post System, or Hinge Series such as Rondo and Classique. All Clamps feature solid brass construction and a variety of finishes to match our Shower Door Hinges. Glass must be drilled with 5/8" or 3/4" (16 or 19 mm) diameter holes to accept Clamps. Appropriate mounting screws and one set of clear gaskets are included with each Clamp. Extra gaskets may be ordered separately.

    CRL Polished Chrome Round Fixed Panel U-Clamp


    Other Products/Finishes:

    RC79CH CRL Polished Chrome Round Fixed Panel U-Clamp

    Catalogue Number:RC79CH
    Also Available in These Catalogues:
    SD16 Frameless Showerscreen Hardware 2015, PAGE 190S
    CRL53R Glass & Glazing Catalogue, PAGE 268G
    CRL23R Frameless Showerscreen and Mirror Hardware, PAGE 286J
    CRL93A Showerscreen, PAGE SD102
    Glass Thickness Range:5/16" to 1/2" (8 to 12 mm)
    Width:2" (52 mm)
    Height:2" (52 mm)
    Ship Via:Can Ship UPS
    Shipping Weight:1 lb (454g)
    Minimum Order:1 Each

  • Glass Thickness: 5/16" to 1/2" (8 to 12 mm)
  • Material: Solid Brass
  • Includes: Mounting Screw and Clear Gaskets
  • Hole Diameter Required: 5/8" or 3/4" (16 or 19 mm)

    NOTE: An additional set of gaskets is required
    for 5/16" (8 mm) glass (Cat. No. UCG77).
