PR72DABG - CRL Brite Gold Delayed Action Adjustable Spring Power Size 1/2 to 4 Surface Mount Door Closer
C.R.LaurenceC.R. Laurence of Australia Pty Ltd.
Connecting the World to Everything Glass
 YOUR ACCOUNT               VIEW CART                SIGN INSIGN OFF
Search


View Larger Image

Catalogue Number: PR72DABG
Finish: BRITE GOLD


  • Multi-Size Adjustable Spring Power Closers Ranging in Sizes BF 1/2 to 6

  • Barrier Free and Delayed Action Models to Meet A.D.A. Barrier-Free Requirements

  • Applicable for Doors Weighing 22 to 330 Lbs. (10 to 150 kg)
  • Aluminum and Dark Bronze Finishes
  • Brite Gold and Chrome Finishes for Restaurants and Upscale Retail Businesses
  • UL Listed
  • Warranty Information and Cross Reference Chart Available

  • The CRL PR70 Series of Multi-Size Adjustable Spring Power Surface Mounted Door Closers are a range of Closers offering A.D.A. Barrier-Free (low opening resistance), Delayed Action models to allow adjustable delayed closing, and heavy-duty full range models for full control of heavier commercial doors. They are also available in Brite Gold and Polished Chrome finishes to complement most architectural finish requirements.



    CRL Brite Gold Delayed Action Adjustable Spring Power Size 1/2 to 4 Surface Mount Door Closer





    Other Products/Finishes:

    CATALOGUE NUMBER DESCRIPTION COLOUR
    PR72DAA CRL Aluminum Delayed Action Adjustable Spring Power Size 1/2 to 4 Surface Mount Door Closer
    PR72DABG CRL Brite Gold Delayed Action Adjustable Spring Power Size 1/2 to 4 Surface Mount Door Closer
    PR72DACH CRL Polished Chrome Delayed Action Adjustable Spring Power Size 1/2 to 4 Surface Mount Door Closer
    PR72DADU CRL Dark Bronze Delayed Action Adjustable Spring Power Size 1/2 to 4 Surface Mount Door Closer

    Catalogue Number:PR72DABG
    Also Available in These Catalogues:
    AH18 Architectural Hardware Catalogue 2018, PAGE 326Z
    CRL63A Architectural Hardware Master, PAGE 434H
    CRL14D Door and Entrance Catalogue, PAGE 438D
    CRL53R Glass & Glazing Catalogue, PAGE 547G
    CRL83R Door and Window Replacement, PAGE 668W
    CRL93A Architectural Hardware, PAGE CH155
    DC14 Door Controls Catalogue 2014, PAGE D309
    Colour:Brite Gold
    Spring Size:1/2 - 4
    Closer Description:Delayed Action/Adjustable
    Ship Via:Can Ship UPS
    Shipping Weight:7.4 lb (3.36kg)
    Case Qty:6
    Minimum Order:1 Each

    The Delayed Action feature adjusts the time a door will remain open to facilitate ease of progress through the opening. This feature is valuable in health care facilities and public buildings that require door closers to momentarily stay open. Closing and latching speed controls are independently adjustable, and an adjustable backcheck feature helps prevent damage to the closer, door, and adjacent structures should the door be violently swung open due to wind or heavy pedestrian traffic.

    All PR70 Closers are UL Listed and warranted for ten years. Parallel Arm Brackets and mounting hardware are included with each closer permitting universal installation for regular, top jamb or parallel arm applications. Optional accessories, such as Drop Plates and Hold Open Arms, are available for special installations.

    Closers set to comply with A.D.A. specified opening forces might not provide adequate spring power to control and close the door due to varying site conditions and door size.
